| Technical Data | |||||||
|---|---|---|---|---|---|---|---|
| Type |
Monaural Moving Coil (Dynamic) “REAL STEREO” Generator System |
||||||
| Cryogenic Treatment | Temperature: -196 ℃ (-320°F) | ||||||
|
X:6N Crystal Copper φ 0.035mm XX:5N Large Crystal Copper φ 0.035mm S:5N Silver φ 0.035mm |
||||||
| Output Voltage | 1.0mV (5.0cm/sec, 1kHz) | ||||||
| Frequency Response ±1dB |
10 Hz - 25 kHz 20 Hz - 18 kHz |
||||||
| Recommended Tracking Force | 2.5gm 〔20゜C-25゜C〕 | ||||||
| Tracking Force Range | 2.0gm - 3.5gm | ||||||
| Trackability | ＞60μm/2.0gm | ||||||
|
12×10-6cm/dyne 12×10-6cm/dyne |
||||||
| Internal Impedance | 10Ω (XX:10Ω S:5Ω) | ||||||
| Load Impedance | ＞ 100Ω | ||||||
| Cantilever Material | ALMg5 tube φ0.45×φ0.30mm | ||||||
| Stylus | Spherical Solid Diamond □0.1mm | ||||||
| Contact Radius, Life Time | 0.7 mil, 1000hour/2.5gm | ||||||
| Output Terminals | φ1.25mm gold plated 〔 EIA 〕 | ||||||
| Terminal Board | Glass Epoxy Plate | ||||||
| Dimensions | 16.8mm(W)×19.0mm(L)×x15.6mm(H) | ||||||
| Net Weight | 4.1gm, 6.8gm(TB2), 8.0gm(SB2) |
