| Technical Data | |||||
|---|---|---|---|---|---|
| Type |
Monaural Moving Coil (Dynamic) “REAL STEREO” Generator System |
||||
| Cryogenic Treatment | Temperature: -196 ℃ (-320°F) | ||||
| Coil Wire | 6N OFCφ0.035mm | ||||
| Output Voltage | 1.0mV (5.0cm/sec, 1kHz) | ||||
| Frequency Response ±1dB |
10 Hz - 25 kHz 20 Hz - 18 kHz |
||||
| Recommended Tracking Force | 2.5gm 〔20゜C-25゜C〕 | ||||
| Tracking Force Range | 2.0gm - 3.5gm | ||||
| Trackability | ＞60μm/2.0gm | ||||
|
12×10-6cm/dyne 12×10-6cm/dyne |
||||
| Internal Impedance | 10Ω | ||||
| Load Impedance | ＞ 100Ω | ||||
| Cantilever Material | ALMg5 tube φ0.45×φ0.30mm | ||||
| Stylus | Spherical Solid Diamond □0.1mm | ||||
| Contact Radius, Life Time | 1.0 mil, 1000hour/2.5gm | ||||
| Output Terminals | φ1.25mm gold plated 〔 EIA 〕 | ||||
| Terminal Board | Glass Epoxy Plate | ||||
| Dimensions | 16.2mm(W)x19.7mm(L)x17.6mm(H) | ||||
| Net Weight | 5.0gm, 7.7gm (TB), 9.0gm(SB) |
